General Specs
Color	Stainless Steel
Appliance Fit Width (in.)	48
Manufacturer Warranty	2 Year Parts & Labor
Capacity (cu ft)	6
Color Finish Name	Stainless Steel
ADA Compliant	No
Range Type	Pro-Style
Number of Elements/Burners	6
Fuel Type	Natural Gas
Number of Oven(s)	Double
Depth (in.)	28.07
Height (in.)	38.3
Width (in.)	47.9
Burner Performance
Broil burner	10,000 BTU
U-shape burner (30” Oven)	22,000 BTU
Tube Burner ( 18? Oven)	14, 000 BTU
Techincal Details
Electrical Requirements	120V
Circuit Breaker (A)	15 or 20 A
Frequency (Hz)	60 Hz
Dimension & Weight
Product height (from bottom to top of back splash)	37.2”
Product height (from bottom to top of side panel)	34.9”
Product depth (from back panel to bullnose include gasket)	27.4”
Product depth (from back panel to control board include gasket)	27.1”
Product depth (from back panel to side panel front include gasket)	24.8”
Depth of control panel (minimum)	2.3”
Depth of control panel (bullnose)	3.5”
Cast iron cooking grate (W x L)	21.85*11”
Adjustable legs	Recommend not to exceed 1”
Power plug length	56.25”
Required Cutout Size (W x D x H) (in)	48.2” x 27.2” x 36”
